MRCOOL Universal Series DC Inverter Variable Complete System Heat Pump 2-3 Ton up to 19 SEER R410A 24,000-36,000 BTU 208-230V/1Ph/60Hz
SKU MDUO18024036 MDUI18024036
$3 555.00
In stock
Product Details
DIY PRE -CHARGED LINESET INSTALLATION KITS SOLD SEPARATELY. THEY ARE SOLD IN 16 FT, 25 FT, OR 50 FT LENGTHS. LENGTH PRICE WOULD DEPEND ON SPECIFIC PROJECT NEEDS. CONTACT US FOR PRICING.
THESE UNITS ARE 24000-36000 BTU SYSTEMS. THESE SYSTEMS WILL EASILY PROVIDE 24-36K BY SIMPLY SETTING A DIP SWITCH. INSTRUCTIONS PROVIDED WITH UNIT.
SHIPPING; DUE TO WEIGHT AND DIMENSIONS THESE UNITS ARE ONLY SHIPPED VIA FREIGHT FROM OUR DISTRIBUTION CENTER.THIS UNIT REQUIRES SHIPPING VIA FREIGHT CARRIER. PLEASE PROVIDE YOUR COMPLETE SHIPPING ADDRESS WHEN CONTACTING TO ORDER. SEE SPECIFICATIONS BELOW FOR MORE SPECIFICS. SHIPPING IS CURRENTLY 40% OFF..
NOTE : YOU WILL NEED TO EMAIL SALES@AFFORDABLEMINISPLITS.COM TO RECIEVE THE DISCOUNTED SHIPPING RATE.
CONDENSOR SPECIFICATIONS
24000 BTU SPECIFICATIONS :
|
BRAND NAME |
MRCOOL |
|
SERIES |
Universal Series Heat Pump |
|
MODEL |
MDUO18024 |
|
GTIN |
00810512032921 |
|
UPC |
810512032921 |
|
UNIT TYPE |
Universal Series Heat Pump |
|
SHORT DESCRIPTION |
2-3 ton up to 20 SEER Universal Series Condenser |
|
LONG DESCRIPTION |
MRCOOL would like to introduce you to the future of HVAC with its new 20 SEER Ultra-Heat Inverter Unitary Condensing Unit and Air Handler. This unit provides superb comfort while running at an extremely quiet dB, rapid cooling and heating, and maximum savings while running on end. Don't be stuck in the past with your traditional system, think ahead with MRCOOL. |
|
BULLET 1 |
Up to 20 SEER |
|
BULLET 2 |
Ultra Wide Operating Temperature Range |
|
BULLET 3 |
Gas Furnace Not Required |
|
BULLET 4 |
Two models 36K/60K, heat pump, to cover 24K-60K capacity range |
|
BULLET 5 |
Slim design allows more storage for warehouse inventory |
|
BULLET 6 |
Compatible with any third party air handler and thermostat including WiFi/Nest |
|
BULLET 7 |
Ideal for zero lot line homes, strict sound restriction, conventional installations, and unit replacements |
|
BULLET 8 |
Rapid cooling and heating |
|
BULLET 9 |
Internal Fan Blade Creates Low Noise |
|
BULLET 10 |
Maximum savings while running |
|
BULLET 11 |
Factory Charged |
|
BULLET 12 |
ETL and AHRI certified |
|
SEER |
up to 20 |
|
MAX SEER |
20 |
|
EER |
12.5 |
|
HSPF |
10.5 |
|
CFM |
447-1330 |
|
TONNAGE |
2_3 Ton |
|
COOLING CAPACITY |
8000-36000 |
|
HEATING CAPACITY |
8000-36000 |
|
VOLTAGE |
208/230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER |
25 A |
|
MIN CIRCUIT AMPACITY |
18 A |
|
COLOR |
Gray |
|
COLOR FAMILY |
Gray |
|
MAX COVERAGE AREA |
1000-1500 |
|
REFRIGERANT TYPE |
R-410A |
|
REFRIGERANT VOLUME |
148.8 oz |
|
DECIBEL RATING |
45-60 |
|
DECIBEL RATING LOW |
45 dBA |
|
DECIBEL RATING HIGH |
62 dBA |
|
INVERTER |
DC |
|
MIN AMBIENT COOL |
5F - 129.2F |
|
MIN AMBIENT HEAT |
-22 F - 75.2F |
|
LINESET INCLUDED |
No |
|
LINE SET LENGTH |
15ft, 25ft, 35ft, 50ft |
|
MAX LINESET LENGTH |
164 FT / 5 |
|
LINESET FITTING TYPE |
Pre-Flaired/Sweat & Quick Connect |
|
LIQUID LINE SIZE |
3/8 in |
|
SUCTION LINE SIZE |
3/4 |
|
COMPRESSOR MOTOR TYPE |
Inverter Rotary |
|
CONDENSER FAN MOTOR TYPE |
Direct Drive |
|
CONDENSER FAN MOTOR HP |
1/5 |
|
CONDENSER FAN MOTOR RPM |
820 |
|
METERING DEVICE |
EEV |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
Yes |
|
UL RECONIZED |
No |
|
UL LISTED |
No |
|
ETL LISTED |
Yes |
|
ETL CERTIFIED |
Yes |
|
LEED CERTIFIED |
No |
|
ENERGY STAR COMPLIANT |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
REGISTERED WARRANTY |
10 Year Registered Limited Warranty |
|
BASE WARRANTY |
5 Year Limited Parts Warranty |
|
BASE PARTS WARRANTY |
5 year limited extended parts warranty |
|
HAS BATTERIES |
No |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS AEROSOL |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
PROPOSITION 65 WARNING |
Yes |
|
RESTRICTED STATES |
No |
|
NET DEPTH |
18-1/8 |
|
NET HEIGHT |
32-1/4 |
|
NET WIDTH |
37 |
|
NET WEIGHT |
217.2 LBS |
|
GROSS DEPTH |
22.6 in |
|
GROSS HEIGHT |
42.6 in |
|
GROSS WIDTH |
38.3 in |
|
GROSS WEIGHT |
240.3 LBS |
|
FREIGHT CLASS |
92.5 |
36000 BTU SPECIFICATIONS;
|
SERIES |
Universal Series Heat Pump |
|
MODEL |
MDUO18036 |
|
GTIN |
00810512032921 |
|
UPC |
810512032921 |
|
UNIT TYPE |
Universal Series Heat Pump |
|
SHORT DESCRIPTION |
2-3 ton up to 18 SEER Universal Series Condenser |
|
LONG DESCRIPTION |
MRCOOL would like to introduce you to the future of HVAC with its new 18 SEER Ultra-Heat Inverter Unitary Condensing Unit and Air Handler. This unit provides superb comfort while running at an extremely quiet dB, rapid cooling and heating, and maximum savings while running on end. Don't be stuck in the past with your traditional system, think ahead with MRCOOL. |
|
BULLET 1 |
Up to 18 SEER |
|
BULLET 2 |
Ultra Wide Operating Temperature Range |
|
BULLET 3 |
Gas Furnace Not Required |
|
BULLET 4 |
Two models 36K/60K, heat pump, to cover 24K-60K capacity range |
|
BULLET 5 |
Slim design allows more storage for warehouse inventory |
|
BULLET 6 |
Compatible with any third party air handler and thermostat including WiFi/Nest |
|
BULLET 7 |
Ideal for zero lot line homes, strict sound restriction, conventional installations, and unit replacements |
|
BULLET 8 |
Rapid cooling and heating |
|
BULLET 9 |
Internal Fan Blade Creates Low Noise |
|
BULLET 10 |
Maximum savings while running |
|
BULLET 11 |
Factory Charged |
|
BULLET 12 |
ETL and AHRI certified |
|
SEER |
up to 18 |
|
MAX SEER |
18 |
|
EER |
11 |
|
HSPF |
10 |
|
CFM |
447-1330 |
|
TONNAGE |
2_3 Ton |
|
COOLING CAPACITY |
8000-36000 |
|
HEATING CAPACITY |
8000-36000 |
|
VOLTAGE |
208/230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER |
40 A |
|
MIN CIRCUIT AMPACITY |
24 A |
|
COLOR |
Gray |
|
COLOR FAMILY |
Gray |
|
MAX COVERAGE AREA |
1000-1500 |
|
REFRIGERANT TYPE |
R-410A |
|
REFRIGERANT VOLUME |
148.8 oz |
|
DECIBEL RATING |
45-62 |
|
DECIBEL RATING LOW |
45 dBA |
|
DECIBEL RATING HIGH |
62 dBA |
|
INVERTER |
DC |
|
MIN AMBIENT COOL |
5F - 129.2F |
|
MIN AMBIENT HEAT |
-22 F - 75.2F |
|
LINESET INCLUDED |
No |
|
LINE SET LENGTH |
15ft, 25ft, 35ft, 50ft |
|
MAX LINESET LENGTH |
164 FT / 5 |
|
LINESET FITTING TYPE |
Pre-Flaired/Sweat & Quick Connect |
|
LIQUID LINE SIZE |
3/8 in |
|
SUCTION LINE SIZE |
3/4 |
|
COMPRESSOR MOTOR TYPE |
Inverter Rotary |
|
CONDENSER FAN MOTOR TYPE |
Direct Drive |
|
CONDENSER FAN MOTOR HP |
1/5 |
|
CONDENSER FAN MOTOR RPM |
820 |
|
METERING DEVICE |
EEV |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
Yes |
|
UL RECONIZED |
No |
|
UL LISTED |
No |
|
ETL LISTED |
Yes |
|
ETL CERTIFIED |
Yes |
|
LEED CERTIFIED |
No |
|
ENERGY STAR COMPLIANT |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
REGISTERED WARRANTY |
10 Year Registered Limited Warranty |
|
BASE WARRANTY |
5 Year Limited Parts Warranty |
|
BASE PARTS WARRANTY |
5 year limited extended parts warranty |
|
HAS BATTERIES |
No |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS AEROSOL |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
PROPOSITION 65 WARNING |
Yes |
|
RESTRICTED STATES |
No |
|
NET DEPTH |
18-1/8 |
|
NET HEIGHT |
32-1/4 |
|
NET WIDTH |
37 |
|
NET WEIGHT |
217.2 LBS |
|
GROSS DEPTH |
22.6 in |
|
GROSS HEIGHT |
42.6 in |
|
GROSS WIDTH |
38.3 in |
|
GROSS WEIGHT |
240.3 LBS |
|
FREIGHT CLASS |
92.5 |
24000 BTU AIR HANDLER
|
BRAND NAME |
MRCOOL |
|
SERIES |
Universal Series Air Handler |
|
MODEL |
MDUI18024 |
|
GTIN |
00810512032983 |
|
UPC |
810512032983 |
|
UNIT TYPE |
Universal Series Air Handler |
|
CONFIGURATION |
Upflow/Horizontal |
|
SHORT DESCRIPTION |
2-3 ton up to 20 SEER Universal Series Air Handler |
|
LONG DESCRIPTION |
MRCOOL would like to introduce you to the future of HVAC with its new 20 SEER Ultra-Heat Inverter Unitary Condensing Unit and Air Handler. This unit provides superb comfort while running at an extremely quiet dB, rapid cooling and heating, and maximum savings while running on end. Don't be stuck in the past with your traditional system, think ahead with MRCOOL. |
|
BULLET 1 |
Up to 20 SEER |
|
BULLET 2 |
Ultra Wide Operating Temperature Range |
|
BULLET 3 |
Gas Furnace Not Required |
|
BULLET 4 |
Two models 36K/60K, heat pump, to cover 24K-60K capacity range |
|
BULLET 5 |
Slim design allows more storage for warehouse inventory |
|
BULLET 6 |
Compatible with any third party air handler and thermostat including WiFi/Nest |
|
BULLET 7 |
Ideal for zero lot line homes, strict sound restriction, conventional installations, and unit replacements |
|
BULLET 8 |
Rapid cooling and heating |
|
BULLET 9 |
Internal Fan Blade Creates Low Noise |
|
BULLET 10 |
Maximum savings while running |
|
BULLET 11 |
Factory Charged |
|
BULLET 12 |
ETL and AHRI certified |
|
SEER |
20 |
|
EER |
12.5 |
|
HSPF |
10.5 |
|
CFM |
900 |
|
TONNAGE |
2_3 Ton |
|
COOLING CAPACITY |
8000-40000 |
|
VOLTAGE |
208/230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER |
15 A |
|
MIN CIRCUIT AMPACITY |
4 AMP |
|
COLOR |
Gray |
|
COLOR FAMILY |
Gray |
|
MAX COVERAGE AREA |
1000-1500 |
|
REFRIGERANT TYPE |
R-410A |
|
DECIBEL RATING |
45 |
|
DECIBEL RATING HIGH |
45 dBA |
|
INVERTER |
DC |
|
LINESET INCLUDED |
No |
|
LINE SET LENGTH |
15ft, 25ft, 35ft, 50ft |
|
MAX LINESET LENGTH |
164 FT / 5 |
|
LINESET FITTING TYPE |
Pre-Flaired/Sweat & Quick Connect |
|
LIQUID LINE SIZE |
3/8 in |
|
SUCTION LINE SIZE |
3/4 |
|
FILTER TYPE |
Replaceable |
|
METERING DEVICE |
TXV |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
Yes |
|
AUXILIARY HEATER SIZES |
5kw,8kw,10kw |
|
ENERGY STAR COMPLIANT |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
REGISTERED WARRANTY |
10 Year Registered Limited Warranty |
|
BASE WARRANTY |
5 Year Limited Parts Warranty |
|
BASE PARTS WARRANTY |
5 year limited extended parts warranty |
|
HAS BATTERIES |
No |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS AEROSOL |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
PROPOSITION 65 WARNING |
Yes |
|
RESTRICTED STATES |
No |
|
NET DEPTH |
21-1/4 |
|
NET HEIGHT |
48-1/4 |
|
NET WIDTH |
21-1/4 |
|
NET WEIGHT |
156.5 LBS |
|
GROSS DEPTH |
26 in |
|
GROSS HEIGHT |
50.4 in |
|
GROSS WIDTH |
23.7 in |
|
GROSS WEIGHT |
169.8 LBS |
|
FREIGHT CLASS |
100 |
|
IMAGE 1 |
|
|
IMAGE 2 |
|
|
IMAGE 3 |
|
|
IMAGE 4 |
|
|
IMAGE 5 |
|
|
IMAGE 6 |
|
|
IMAGE 7 |
|
|
IMAGE 8 |
|
|
IMAGE 9 |
|
|
IMAGE 10 |
|
|
VIDEO 1 |
|
|
BROCHURE |
|
|
INSTALL MANUAL |
|
|
SPECS |
|
|
OWNER MANUAL |
|
|
WARRANTY DOC |
