BRAND NAME

MRCOOL

SERIES

DIY 5th gen Single-Zone Mini-splits

MODEL

DIY-18-HP-WMAH-230D25-O

GTIN

00840255587044

UPC

840255587044

SHORT DESCRIPTION

MRCOOL® 18k DIY 5th Generation Mini-split Air Handler 230v

LONG DESCRIPTION

The 5th Generation MRCOOL® DIY® 18k BTU Ductless Heat Pump Single Zone Mini-Split Air Handler delivers powerful, energy-efficient heating and cooling for spaces up to 800 sq. ft. Designed for easy, tool-free installation, this system requires no professional experience, specialized tools, or costly service calls—making it a fast and affordable comfort solution for homeowners. This model features the rugged DIYPRO® cable, which eliminates the need for traditional electrical conduit while offering added durability and protection against outdoor elements, animals, and harsh weather conditions. Installation is not only simplified but also built to last. You can manage your comfort your way. Use the included wireless remote, connect through the SmartHVAC app available on iOS and Android devices, or control the system using voice commands via Amazon Alexa and Google Assistant. The Gold Fin® condenser coating enhances corrosion resistance, making the unit a great fit for coastal or high-humidity areas. The system also includes advanced comfort features. Follow Me® technology senses the temperature around the remote and adjusts airflow accordingly, ensuring consistent comfort where you are. Dry Mode reduces humidity for better air quality and comfort. To protect your investment, MRCOOL® offers a strong 7-year compressor and 5-year parts warranty, and is also eligible for the MRCOOL® Care Program. Experience hassle-free installation, advanced features, and reliable year-round comfort with the MRCOOL® DIY® 18k Mini-Split Air Handler.

FEATURE LIST

• Intertek listed 5031495
• Easy DIY installation
• Future-proof your investment with the included DIYPro® cable, eliminating the need for electrical conduit.
• Keep the included remote close by, and MRCOOL DIY®'s Follow Me® function will track the air temperature around you to ensure maximum comfort.
• The MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.

TONNAGE

1.5

VOLTAGE (V)

208/230

PHASE

1

CYCLE

60

MAX FUSE BREAKER (A)

15

MIN CIRCUIT AMPACITY (A)

3

MOUNT TYPE

Wall

COLOR

White

MAX COVERAGE AREA

800 sqft

DECIBEL RATING LOW (DBA)

19

DECIBEL RATING HIGH (DBA)

54.5

NUMBER OF SPEEDS

5

OSCILLATION

Yes

LIQUID LINE SIZE

1/4

SUCTION LINE SIZE

1/2

FILTER TYPE

Reusable

AUXILIARY HEATER INCLUDED

No

AUXILIARY HEATER AVAILABLE

No

FAN ONLY OPTION

Yes

QUIET MODE

Yes

AUTO COOL

Yes

WIFI COMPATIBILITY

Yes

APP COMPATIBILITY

Yes

WORKS WITH IOS

Yes

WORKS WITH ANDROID

Yes

REMOTE CONTROL INCLUDED

Yes

UL LISTED

Yes

ETL LISTED

Yes

ENERGY STAR CERTIFIED

Yes

AHRI CERTIFIED

Yes

BASE PARTS WARRANTY

5

BASE COMPRESSOR WARRANTY

7

HAS BATTERIES

Yes

CONTAINS ELECTRONICS

Yes

CONTAINS CHEMICALS

Yes

CONTAINS AEROSOL

Yes

CONTAINS COMPRESSED GAS

Yes

PROPOSITION 65 WARNING

Yes

NET DEPTH (IN)

8.9

NET HEIGHT (IN)

13.19

NET WIDTH (IN)

42.52

NET WEIGHT (LBS)

35.49

GROSS DEPTH (IN)

17.68

GROSS HEIGHT (IN)

14.29

GROSS WIDTH (IN)

46.73

GROSS WEIGHT (LBS)

49.6
